|Application::||River Water Filtration||Treatment Process::||Flocculation&sedimentation&filtrat|
|Body Material::||Carbon Steel With Epoxy Coating||Capacity::||100 000 Liter Per Hour|
|Raw Water::||River Water/Surface Water||Control System::||PLC Control System|
industrial water treatment plant,
industrial water purification system
river rivulet stream water filtration treatment plant water small treatment plant
|Product Grouping||Integrated Purifier|
|Applicatio||Electronic,power,photovoltaic,beverage,medicine,middle water recycling and sea water desalination,drinking|
|Features||Small equipment,easy transportation|
process flow chart
Raw water → water collecting pump→mixing pipe→integrated high-effected auto-backwashed filtering device →clean water pond →lift pump→water use point ↑
Note: both water collecting pump and lift pump are not covered in the quote.
water filtering process description
process features and equipment function description
1, most outstanding features the filtering process
1.1 Short construction period with equipment manufacturing and civil construction being performed simultaneously. It can be even shortened by half time compared with civil-work project.
1.2 Proactive and flexible system arrangement. Suppose production of water is required to increase, you can make it by only adding a set of equipment in a related size. This can miss the limitations of using civil-work
1.3 the system adopts commonly-used rotational flow reacting which features simple structure and provides high efficiency in producing large flocs(alumen ustum). It can even achieve a level two times higher than normal vertical flow reacting. Consequently ,rotational flow is very workable process prior to sedimentation .
1.4 Sedimentation of the system occupies larger area than conventional vertical flow sedimentation and thus displays a high efficiency than vertical flow sedimentation equipment.
1.5 Main equipment is made of steel with corrosion resistant and includes no moving part. The life time of the equipment can last up to 15 years.
1.6 The integrated structure of the system requires 50% smaller footprint than civil water filtering plant(Civil gravity sedimentation tank + civil valveless siphon filter tank) . Besides, it requires water for backwash at amount 30% less than civil plant due to it’s higher efficiency in precipitation and no need for consumption of water from clean water tank.
