Product Details:
|
| Product Name: | Cartridge Filter For Water Treatment | Application1: | Pharmaceuticals |
|---|---|---|---|
| Application2: | Fine Chemicals, Water Treatment | Filter Length: | 10"---40" |
| Application3: | Food&Beverage,etc | Replace The Pressure: | 0.05Mpa-0.07MPA |
| Highlight: | stainless steel filter housing,ro membrane vessel |
||
Product Name:Stainless steel beer precision water cartridge filter for water treatment
The Product Profile :
The cartridge filter consists of cartridge body,filter basket ,hoses ,flanges ,and commonly-used fasteners.It can be installed in the pipes to remove particles, therefore,ensures the fuction of the equipments(including condensing machine,pumps and etc)and instruments to guarantee stable process and safe manufacture.When the fluid flows through the cartridge and enters the filter basket, the solid particles are retained in the baskets .And clean fluid is obtained, and flows out from the filter’s exit. When cleaning is needed ,unscrew the bottom plug ,drain the fluid ,remove the flange ,re-install the parts after cleaning .Therefore,It’s very convenient to use and maintain the machine .
| Material of filter | Temperature(℃) | Pressure(Mpa) | Precision(μm) | Size(mm) |
| Sintered titanium alloy filter | ≤300 | 0.015 | 0.3~100 | Φ50×120 Φ50×450 Φ60×110 Φ60×300 Φ60×500 Φ60×1000 |
| Stainless plait filter | ≤500 | 0.01 | 2~180 | Φ35×210 Φ65×250 Φ86×350 Φ86×500 Φ90×1000 |
| PTFE plait filter | ≤140 | 0.011 | 0.02~50 | Φ45×250 Φ45×500 Φ45×1000 Φ60×250 Φ60×500 Φ60×1000 |
| PP plait filter | ≤60 | 0.012 | 0.1~60 | Φ45×250 Φ45×500 Φ45×1000 Φ60×250 Φ60×500 Φ60×1000 |
| Metal fiber sintered felt | ≤130 | 0.01 | 1~70 | Φ180×425 Φ180×800 Φ180×1000 |
| Ceramic filter | ≤250 | 0.018 | 0.4~80 | Φ100×300 |
| Melt-down filter | ≤60℃ | 0.015 | 1-100 |
Φ60×250 Φ60×500 Φ60×750 Φ60×1000 |
| Wound filter | ≤60℃ | 0.012 | 1-100 |
Φ60×250 Φ60×500 Φ60×750 Φ60×1000 |
