Product Details:
|
| Technique: | Ion Exchange | Function: | Water Softening |
|---|---|---|---|
| Capacity: | 2m3/h | Filter Hosing: | FRP |
| Filter Media: | Resin | Operating: | Automatic |
| Piping: | UPVC | Certificates: | BV&TUV&ISO |
| Valves: | Auto Control Valves | Installation: | Foundation-mounted |
| Highlight: | ion exchange water treatment plant,ion exchange ro water purifier |
||
FRP water ionizer /water treatment plant HJ-DECEM68
High-tech Enterprise/ Technological Enterprise/ISO9001 Certificated
Multi-Media filter
This equipment is mainly used for removing big particles, seston and colloid from water for dropping turbidity,
and is applicable for the pretreatment of various water or primary filter for industrial water of low quality. The
filter material is quartz sand, anthracite and pyrite ore which shall be selected according to the actual
demands. The equipment enclosure is made of glass fiber reinforced plastic, A3 plastic lined steel and stainless steel. It applies manual control and imported Autotrol/Fleck multiple valve control.
Active carbon filer
Active carbon filter mainly removes remained chlorine(exceeding 98%)from water with the porous and
adsorbing nature of active carbon , and can also effectively remove organic, colloid, heavy metal, pigment and odor. The equipment can be used for the pretreatment phase for reverse osmosis, ultrafiltration and ion
exchange system, and can improve the quality ofinput water of various water treatment equipments and
assure the effective and stable work of followup equipment.
Fully automatic water softener
Water softener is applicable for boiler, circulating water for central air conditioner, and soft water for chemical,
light textile and medicine industries, or equipment for preventing scale.Fully automatic Water Softener applies imported Autotrol Fully Automatic Multiple Valve control, and the entire work procedure, including exchange
softening, blackwash, salt feeding , regenerating and cleaning, is controlled with automatic control system
rather than manual control.
Precise filter
Series precise filter composes of stainless steel enclosure and filter core whose precision grade ranges 0.1um100um for protecting the reverse osmosis membrane from particles and seston, and is also used for removing bacterium and clarifying in medicine and wine. It requires replacing the filter core when the input and output
water pressure difference exceeds 0.1MPa after using for 1-6months.
1.Applications:
1. Feed water of steam boiler, hot water boiler exchanger,evaporative condenser,air conditioner ect.
2. Domestic water of hotel, restaurant, office building, apartment ect;
3. Water softening for food and beverage, brewing, washing, printing, chemical and medicine ect.
2. Flow chat:
raw water+raw water pump+multimedia filter+activated carbon filter+water softener+precise filter+water use point
3. Scheme for reference:
No | Name of device | Specification | Material | Country of origin | Quantity |
1. | Raw water pump | CHL2-50 | Stainless steel | China/Nanfang | 1 set |
2.
| Multimedia filter | Φ400*1650 | FRP | China/Hongjun | 1 set |
Silica sand | 0.6~1.5 | Silica sand | China/Guangdong | 200kg | |
Valve | DN25 | Combination | China/Wenzhou | 1 set | |
3.
| Activated carbon filter | Φ400*1650 | FRP | China/Hongjun | 1 set |
Activated carbon | 12~16 | Activated carbon | China/Hebei | 75kg | |
Valve | DN25 | Combination | China/Wenzhou | 1 set | |
4.
| Precise filter | Φ200*550 | Stainless steel | China/Hongjun | 1 set |
Filter element | 20"*5um | PP | China/Zhejiang | 5 pcs | |
5.
| Water softener | Φ400*1650 | FRP | China/Beijing | 2 sets |
Cation resin | 001*7 | Combination | China/Hongzhou | 300L | |
Regeneration control | manual | Combination | China/Wenzhou | 2 sets | |
Regeneration salt tank | 1000L | PE | China/Guangdong | 1 set | |
6.
| Pressure meter | Φ68 | Stainless steel | China/Guangzhou | 3 sets |
Pressure control | CK2 | Combination | Korea | 1 set | |
Pipeline fitting | DN25 | UPVC | China/Hongjun | 1 set | |
7. | Control system | Operate automatically, electric parts use Schneider | |||
Foshan Hongjun Water Treatment Equipment Co., Ltd. is a professional water treatment
equipment manufacturer, with more than 17 years specializing in the design, manufacture,
fabrication, installation, technology development and sales support of water treatment equipment.
We have advanced techniques, i.e. EDI, RO, NF, UF and MF to provide project design,
construction, operation project and all-in-one service for different types of users in
semiconductor, pharmacy, petrochemical, food and light industries. We serve many famous
engineering companies at home and abroad.We are looking forward to cooperating with you.
OUR CERTIFICATIONS
OUR PRODUCTION AND COORDINATION
Our company activities:
Dear client.
Many thanks for you take attention to our products. At here wish our products and our sincerity service can solve all your questions.
1. Where is the feed water from?
Ans:Make water analysis report?(eg. borehole water, river water. The total dissolved solid, Fe, Mg, Hardness etc. whether over proof
2. After treatment, How much liter flow rate per hour you required?
Ans:Because our plants are designed according to per hours output.
3. After treated, what is the water quality required or standard?
Ans:Meeting WHO drinking standard or industry filed.
If you don’t have water analysis report. Please tell us the water situation/condition. For example the color, odor, turbidity. Underground or river water or other feed water?
So we can do the right solution and price for you.
